This available for purchase cad generated dxf file contains four professionally designed profile template drawings with much information to create cutters for this beautiful handrail cap detail. We always provide enough blend area within the knife design, so no one will ever realize where one molding cutter begins or ends.
For knife quoting purposes, click to open the calculator below; we have added only the important measurements; enter the appropriate dimension in the boxes provided. A brief detailed explanation of how to use the calculator is located here.
Width = 4.000" / Depth of Cut = .282" (top knives) & .250" (bottom cutters.)
Thickness = 1.000" / Depth of Cut = .406" (right blades) & .500" (left cutters).
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
