Base Moulding 4-1/2" - 35

Base Moulding 4-1/2" - 35

This Base Moulding 4-1/2" - 35 measures 4.500" wide by .625" thickness, with a .398" depth of cut on the top horizontal set of moulding knives. Please search our backout category for an appropriate relief cut for this pattern, we have a few options for you to choose from.

The stylish profile is comprised of a 1-29/32" wide horizontal line connected to two 3/32" radius quarter round circles with an attached sunk fillet, connected to an elongated cyma reversa that transitions into a 9/64" radius half round circle flanked by two quarter round beads, merged with a 13/64" radius congee positioned at the top of the profile.

Try one of our fancy base shoe or plant on moulding designs on the bottom of the profile, find an irresistibly compelling pattern by simply changing the width search parameters. Let us assist you in shaping your home’s astonishing architectural decor, one attractive moulding profile at a time.

Molding Knife Calculator

Moulding Size
(inches)

fraction
/

Depth of Cut
(inches)

fraction
/

Grade of Steel

Subtotal

$0.00
$0.00
$0.00

Custom Moulding Template

$35.00
$35.00
$35.00

Total
(Template & 2 Knives)

$0.00
$0.00
$0.00

Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%

To purchase a copy of this template ready dxf file for creating acrylic templates to produce knives please send $5.00 via PayPal.Me/MirrorReflections we will email you the dxf file shortly after payment is received.
