Casing Moulding Profile 4-1/2" - 9

Casing Moulding Profile 4-1/2" - 9

This Casing Moulding Profile 4-1/2" - 9 measures 4.500 wide by 1.000" thickness, the profile is comprised of 1-11/16" fillet that transitions into a 1/4" radius cong'e (cove that is tangent off a straight line) which is connected to a 1" wide 1-1/2" radius shallow cove on the thin side of the pattern. Try enhancing this detail with one of our many backband profiles located in the Caps category of our catalog.

Molding Knife Calculator

Moulding Size
(inches)

fraction
/

Depth of Cut
(inches)

fraction
/

Grade of Steel

Subtotal

$0.00
$0.00
$0.00

Custom Moulding Template

$35.00
$35.00
$35.00

Total
(Template & 2 Knives)

$0.00
$0.00
$0.00

Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%

To purchase a copy of this template ready dxf file for creating acrylic templates to produce knives please send $5.00 via PayPal.Me/MirrorReflections we will email you the dxf file shortly after payment is received.
