Chair Rail Moulding 2-3/4"

Chair Rail Moulding 2-3/4"

Chair Rail Moulding 2-3/4"

This symmetrical chair rail moulding 2-7/8" measures 2.875" wide by .625" thickness. The beaded profile is comprised of a 1-5/8" wide by 1/4" tall raised fillet with 1/8" eased edges in the center, flanked by two 1/16" wide sunk fillets attached to a 1/4" radius half-circle on each side, the beads are recessed by .010" just in case the profile needs a light sanding on top after milling.

Try one of our 125% concentration ultimate CBN (cubic boron nitride) grinding wheels, finish grinding at 3000 rpm with a twenty-degree back clearance angle will create a superior micro edge on all your high-speed steel profile knives. Read this article or watch the videos to help better understand how to align a borazon wheel to axial constant position on a Weinig R 960 profile grinder. During the machining process, the cutters will be capable of milling some of the finest quality architectural mouldings you have ever produced.

For knife quoting purposes, use the calculator below; we have added only the important dimensions. A brief detailed explanation on how to use the calculator is located here.

Width = 2.750" / Depth of Cut = .414" (top knives).

Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%

To purchase this CAD generated, “template ready moulding dxf file” , please send $11.00 to PayPal.Me/MirrorReflections we will email you the precision drawing shortly after the payment is received.
