Crown 2-7/8" - 10
Crown 2-7/8" - 10
This 2-7/8" - 10 crown mould measures 2.889" wide by .813" thickness. The profile comprises a scotia-type cove in the center flanked by notched fillets attached to horizontal and vertical fillets. The spring angles are fixed at thirty-eight and fifty-two degrees, setting the installed height at 2-1/4" tall with a projection of 1-13/16" wide. Two high points in the design are intentionally positioned on the same level plane to assure superior hold-down conditions while milling this pattern on an industrial moulder
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
Right Cutter Head
Thickness: 1.625
Depth of Cut: 0.520
Left Cutter Head
Thickness: 1.625
Depth of Cut: 0.459
Top Cutter Head
Width: 2.875
Depth of Cut: 0.489
Bottom Cutter Head
Width: 0.000
Depth of Cut: 0.000
Grades of Steel
Price Per Cutter Head - Includes Template & Two Knives
*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you
currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$166.50
$166.50
$231.50
Not Needed
Total:
$564.50
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$176.00
$176.00
$246.00
Not Needed
Total:
$598.00
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$190.25
$190.25
$267.75
Not Needed
Total:
$648.25
To purchase this CAD generated,
“template ready moulding dxf file”
, please send $11.00 to
PayPal.Me/MirrorReflections
we will email you the precision drawing shortly after the payment is received.
