Crown 3-3/8" - 11
Crown 3-3/8" - 11
This distinctive 3-3/8" -11 crown mould measures 3.375" wide by .687" thickness. The attractive profile is comprised of two tangent radiuses creating a cyma recta in the center, attached to a 21/64" tall vertical fillet on top, connected to a 7/32" radius bullnose below, joined to a 19/64" radius cove flanked by a 13/32" tall vertical fillet above, and a 3/16" wide horizontal fillet at the bottom of the pattern. The spring angles are fixed at thirty-eight and fifty-two degrees; search our bevels category by these degrees to find back bevel cutters appropriate for this beautiful crown moulding design, these specific back bevels set the installed height at 2-11/16" tall with a projection of 2-3/64" wide.
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
Right Cutter Head
Thickness: 1.625
Depth of Cut: 0.505
Left Cutter Head
Thickness: 1.625
Depth of Cut: 0.551
Top Cutter Head
Width: 3.375
Depth of Cut: 0.243
Bottom Cutter Head
Width: 0.000
Depth of Cut: 0.000
Grades of Steel
Price Per Cutter Head - Includes Template & Two Knives
*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you
currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$172.25
$172.25
$266.75
Not Needed
Total:
$611.25
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$181.75
$181.75
$283.25
Not Needed
Total:
$646.75
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$196.00
$196.00
$308.00
Not Needed
Total:
$700.00
To purchase this CAD generated,
“template ready moulding dxf file”
, please send $11.00 to
PayPal.Me/MirrorReflections
we will email you the precision drawing shortly after the payment is received.
