Crown 4" - 21
Crown 4" - 21
This creative 4" - 21 crown mould measures 4.000" wide by .812" thickness. The ornate profile comprises a combination of stylish geometrical shapes, including fillets, cyma recta, cavettos, and a half-round bead positioned at the bottom of the pattern. The spring angles are fixed at thirty-eight and fifty-two degree, search our bevels category by degree, find a set of back bevel cutters appropriate for this crown design. These specific back bevels set the installed height at 3-1/8" tall, with a 2-1/2" wide projection.
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
Right Cutter Head
Thickness: 1.625
Depth of Cut: 0.644
Left Cutter Head
Thickness: 1.625
Depth of Cut: 0.593
Top Cutter Head
Width: 4.000
Depth of Cut: 0.480
Bottom Cutter Head
Width: 0.000
Depth of Cut: 0.000
Grades of Steel
Price Per Cutter Head - Includes Template & Two Knives
*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you
currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$176.00
$166.50
$290.00
Not Needed
Total:
$632.50
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$185.50
$176.00
$309.00
Not Needed
Total:
$670.50
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$199.75
$190.25
$337.50
Not Needed
Total:
$727.50
To purchase this CAD generated,
“template ready moulding dxf file”
, please send $11.00 to
PayPal.Me/MirrorReflections
we will email you the precision drawing shortly after the payment is received.
