Crown 4-3/16"
Crown 4-3/16"
This beaded 4-3/16" crown mould measures 4.226" wide by .875" thickness requiring five-quarter lumber for milling. The semicircular profile is composed of a 2-3/4" cove flanked by small vertical and horizontal lines in the center, attached to a 7/16" arc that joins to a two tangent radius elliptical shaped bead on top, the lower elliptical shaped bead is also formed from two tangent radiuses but smaller in size. The spring angles are fixed at thirty-eight and fifty-two degrees, these specific back bevels set the installed height at 3-5/16" tall with a projection of 2-5/8" wide.
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
Right Cutter Head
Thickness: 1.625
Depth of Cut: 0.788
Left Cutter Head
Thickness: 1.625
Depth of Cut: 0.758
Top Cutter Head
Width: 4.187
Depth of Cut: 0.478
Bottom Cutter Head
Width: 0.000
Depth of Cut: 0.000
Grades of Steel
Price Per Cutter Head - Includes Template & Two Knives
*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you
currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$176.00
$176.00
$299.72
Not Needed
Total:
$651.72
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$185.50
$185.50
$319.47
Not Needed
Total:
$690.47
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$199.75
$199.75
$349.09
Not Needed
Total:
$748.59
To purchase this CAD generated,
“template ready moulding dxf file”
, please send $11.00 to
PayPal.Me/MirrorReflections
we will email you the precision drawing shortly after the payment is received.
