Crown 4-7/32" - 5
Crown 4-7/32" - 5
This creative 4-7/32" - 5 crown mould measures 4.229" wide by .843" thickness, enabling the detail to be milled out of four-quarter lumber. The concave profile is comprised of a 2-5/32" radius cove in the center, attached to a 1/4" tall by 17/64" wide notched fillet with a 31/64" vertical line segment at the top. The lower portion consists of a 1/2" tall by 15/64" wide notched fillet with a 49/64" wide horizontal line at the bottom of the pattern. The spring angles are fixed at twenty-four and sixty-six degrees; these template designs are included in the downloadable dxf file available for purchase below. These specific back bevels set the installed height at 3-21/32" tall with a 2-3/16" wide projection.
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
Right Cutter Head
Thickness: 0.843
Depth of Cut: 0.662
Left Cutter Head
Thickness: 0.843
Depth of Cut: 0.151
Top Cutter Head
Width: 4.219
Depth of Cut: 0.782
Bottom Cutter Head
Width: 0.000
Depth of Cut: 0.000
Grades of Steel
Price Per Cutter Head - Includes Template & Two Knives
*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you
currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$141.00
$134.00
$321.26
Not Needed
Total:
$596.26
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$148.00
$141.00
$341.14
Not Needed
Total:
$630.14
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$158.50
$151.50
$370.95
Not Needed
Total:
$680.95
To purchase this CAD generated,
“template ready moulding dxf file”
, please send $11.00 to
PayPal.Me/MirrorReflections
we will email you the precision drawing shortly after the payment is received.
