Crown 5" - 30
Crown 5" - 30
This enthralling 4" - 30 crown mould measures 4.000" width by .813" thickness, allowing the use of four-quarter lumber for milling on a commercial moulder. The asymmetrical supporting profile contains a 15/32" radius convex arc, joined to a 7/32" tall vertical fillet on the top left. The center consists of a two tangent radius cyma recta with a 5/16" tall line segment, this area merges a half-inch radius ovolo flanked by a 17/64" horizontal line on top and two perpendicular lines at the bottom of the design. The set spring angles are at forty-five degrees; these dedicated back bevels keep the face side of the profile parallel to the wall and ceiling when installed, they also lock in the positioned height at 3-1/2" tall with a projection of 3-9/16" across the top.
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
Right Cutter Head
Thickness: 1.625
Depth of Cut: 0.450
Left Cutter Head
Thickness: 1.625
Depth of Cut: 0.400
Top Cutter Head
Width: 5.000
Depth of Cut: 0.511
Bottom Cutter Head
Width: 0.000
Depth of Cut: 0.000
Grades of Steel
Price Per Cutter Head - Includes Template & Two Knives
*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you
currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$166.50
$123.50
(Template not needed)
$342.00
Not Needed
Total:
$632.00
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$176.00
$133.00
(Template not needed)
$365.00
Not Needed
Total:
$674.00
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$190.25
$147.25
(Template not needed)
$399.50
Not Needed
Total:
$737.00
To purchase this CAD generated,
“template ready moulding dxf file”
, please send $11.00 to
PayPal.Me/MirrorReflections
we will email you the precision drawing shortly after the payment is received.
