Crown 5-21/32" - 5
Crown 5-21/32" - 5
This concave 5-21/32" - 16 crown mould measures 5.656" wide by 1.218" thickness, necessitating the use of six-quarter lumber to be machined sprung (laying horizontally flat) on an industrial moulder. The highly decorative supporting profile is comprised of an 11/64" wide by 3/16" tall perpendicular lines on the top left, attached to a small 7/32" radius ovolo with a 3/16" tall line connected to a 2-1/2" cove in the center, joined to a 3/16" wide flat line and an elongated 9/16" radius semicircular arc with a 1/4" wide by 1/4" tall square lines on the bottom right side of the design. The spring angles are fixed at forty-five degrees, these explicit back bevels keep the inner profile parallel to the wall and ceiling; they also set the installed height at 4" tall with a projection of 4" wide.
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
Right Cutter Head
Thickness: 1.625
Depth of Cut: 1.090
Left Cutter Head
Thickness: 1.625
Depth of Cut: 1.090
Top Cutter Head
Width: 5.656
Depth of Cut: 0.854
Bottom Cutter Head
Width: 0.000
Depth of Cut: 0.000
Grades of Steel
Price Per Cutter Head - Includes Template & Two Knives
*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you
currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$176.00
$133.00
(Template not needed)
$401.74
Not Needed
Total:
$710.74
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$185.50
$142.50
(Template not needed)
$427.36
Not Needed
Total:
$755.36
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$199.75
$156.75
(Template not needed)
$465.80
Not Needed
Total:
$822.30
To purchase this CAD generated,
“template ready moulding dxf file”
, please send $11.00 to
PayPal.Me/MirrorReflections
we will email you the precision drawing shortly after the payment is received.
