Search Our Moulding Knives Catalog by Category and Size

*Enter desired search sizes - use whole numbers & decimals

Fluted Moulding 3-5/8" - 1

Fluted Moulding 3-5/8" - 1

Fluted Moulding 3-5/8" - 1

This fluted casing molding 3-5/8" - 2 measures 3.625" wide by .750" thickness, permitting the use of four quarter lumber for milling on a commercial-grade molder. The straightforward pattern contains four 1/2" wide concave semicircular arcs divided by three 5/16" wide fillets in the center, the right and left edges retain a 11/32" wide line segments.

Look for a few other profile designs for different rooms in your beautiful, stylish home, with over 15,000 patterns in our search by size molding catalog there is something for everyone's creative architectural style. Utilize our manufacturers map listed by states to help you locate a mill in your area to produce any of our attractive profiles.

For molding knife quoting purposes, click to open the calculator below; we supplied only the important measurements, enter the appropriate dimension in the boxes provided. A brief detailed explanation on how to use the calculator is located here. If you would like some assistance with the dimensions, print a copy of our fraction - decimal - millimeter chart, place it on the molder or around the shop to help machine operators save time and increase accuracy during setup procedures.

Width = 3.625" / Depth of Cut = .250" (top knives) & .063" (bottom cutters).

Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%

To purchase this CAD generated, “template ready moulding dxf file” , please send $11.00 to PayPal.Me/MirrorReflections we will email you the precision drawing shortly after the payment is received.
