Handrail 2-5/8" - 31

Handrail 2-5/8" - 31

Handrail 2-5/8" - 31

This modern 2-5/8" - 32 handrail measures 2.625" wide by 2.375" thickness, allowing the pattern to be machined out of glued-up pieces of four-, five-, or six-quarter lumber. The width of the detail can be adjusted to any desired size because the profile is machined from the left and right cutter heads on the moulder. The beautiful symmetrical design composes a flat top tangent to a 13/16" tall bullnose edge on each side, connected to a 1/8" tall concave semicircle which creates a comfortable finger grip area, joined to a 1-7/64" tall, straight line in the center, merged with a 5/64" tall sunk fillet at a 1-3/4" width and a decorative 1/4" half round bead at a two-inch width at the bottom of the profile.

Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%

Right Cutter Head
Thickness: 2.375
Depth of Cut: 0.593
Left Cutter Head
Thickness: 2.375
Depth of Cut: 0.593
Top Cutter Head
Width: 0.000
Depth of Cut: 0.000
Bottom Cutter Head
Width: 0.000
Depth of Cut: 0.000

Grades of Steel

Price Per Cutter Head - Includes Template & Two Knives

*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$199.25
$156.25
(Template not needed)
Not Needed
Not Needed
Total:
$355.50
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$211.75
$168.75
(Template not needed)
Not Needed
Not Needed
Total:
$380.50
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$224.25
$181.25
(Template not needed)
Not Needed
Not Needed
Total:
$405.50
To purchase this CAD generated, “template ready moulding dxf file” , please send $11.00 to PayPal.Me/MirrorReflections we will email you the precision drawing shortly after the payment is received.
