This beautifully tall handrail 2-3/4" - 26 measures 2.750" wide by 3.375" tall, necessitating the use of glued up pieces of four, five or six quarter lumber to manufacture the blank for milling this detail on a industrial moulder. The modern profile is composed of a 1/16" radius point flanked by two bidirectional 10.784 degree angled lines with 1/16" eased edges on the top, the sides consists of a 5/8" tall by 1/8" wide perpendicular lines joined to a two tangent radius ogee derived from two 5/32" semicircles with a 3/32" wide inset line in the upper portion, attached to a 2-1/8" tall line segment with 1/16" round-overs on the lower edges, the baluster dado measures 1-1/4" wide by 3/8" deep, leaving two 3/8" wide line segments on the bottom edges.

This cad generated dxf file (purchase in the link below) contains three skillfully drafted template designs for producing knives for this creative handrail pattern. All our innovative profiles have a proven unbroken computer numerical control (CNC) tool path expediting the production process.

For knife quoting purposes click to open the calculator below, we have added only the important measurements, just enter the appropriate dimension in the boxes provided. A brief detailed explanation on how to use the calculator is located here. Need some assistance with the dimensions? Print a copy of our fraction - decimal - millimeter chart, place it on the molder to help operators save time and increase accuracy during machine setup.

Width = 2.750" / Depth of Cut = .468" (top knives) & .375" (bottom cutters.)

Thickness = 3.375" / Depth of Cut = .592" (right blades) & .592" (left cutters.)

Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%

To purchase this CAD generated, “template ready moulding dxf file” , please send $11.00 to PayPal.Me/MirrorReflections we will email you the precision drawing shortly after the payment is received.
