Picture Frame 3-3/4" - 11
Picture Frame 3-3/4" - 11
This ornate picture frame measures 3-3/4" wide by 2-3/32" thickness and this detailed and unique profile have too many intricate portions to describe correctly. It will require three profiling spindles on an industrial molder to manufacture this pattern, right, left, and top. The top cut will be significant to eliminate potential finish problems. It will require a custom pressure shoe to hold this profile down on the bedplate while milling.
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
Right Cutter Head
Thickness: 2.125
Depth of Cut: 0.653
Left Cutter Head
Thickness: 2.125
Depth of Cut: 0.687
Top Cutter Head
Width: 3.750
Depth of Cut: 1.125
Bottom Cutter Head
Width: 0.000
Depth of Cut: 0.000
Grades of Steel
Price Per Cutter Head - Includes Template & Two Knives
*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you
currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$204.00
$204.00
$295.00
Not Needed
Total:
$703.00
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$215.50
$215.50
$313.00
Not Needed
Total:
$744.00
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$232.75
$232.75
$340.00
Not Needed
Total:
$805.50
To purchase this CAD generated,
“template ready moulding dxf file”
, please send $11.00 to
PayPal.Me/MirrorReflections
we will email you the precision drawing shortly after the payment is received.
