Plinth Block 8" - 7

Plinth Block 8" - 7
This plinth block measures 8" wide by 1" thick. The design comprises a recessed center bead with chamfers on both sides, large and small fillets, and a cyma recta attached to a half-round bead on the top of the profile.
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
To purchase this CAD generated,
“template ready moulding dxf file”
, please send $11.00 to
PayPal.Me/MirrorReflections
we will email you the precision drawing shortly after the payment is received.
