Shutter/Louver 3-1/8"

Shutter/Louver 3-1/8"

Shutter/Louver 3-1/8"

This false louver 3-1/8" measure .687" wide by 3.750" tall, allowing the use of a 3-5/8" wide blank of four-quarter lumber for milling on an industrial-style molder. The decorative profile contains three consecutive sections consisting of a twelve-degree angled line with a 5/32" radius edge. The tongue dimension is 1/4" tall by 1/4" deep, the groove is 9/32" tall by 1/4" in depth with a .016" void in the joint area for expansion and contraction of the lumber during seasonal changes in relative humidity. When two pieces of milled lumber get joined, they create a false louver at a face coverage dimension of 3-1/8" tall.

Architects, interior designers, contractors, lumber mills, cabinet shops, and molding manufacturers are utilizing our wide variety of molding designs. We trust you will find that special profile to enhance the architectural style of your client's home or office. Be sure to download all our free dxf files; see how easily the services we provide can increase productivity and reduce your manufacturing cost.

For knife quoting purposes, click to open the calculator below; we supplied only the important measurements; enter the appropriate dimension in the boxes provided. A brief detailed explanation of how to use the calculator is located here.

Width = 3.375" / Depth of Cut = .312" (top knives) & .312" (bottom cutters).

Thickness = .687" / Depth of Cut = .281" (right blades) & .250" (left cutters).

Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%

To purchase this CAD generated, “template ready moulding dxf file” , please send $11.00 to PayPal.Me/MirrorReflections we will email you the precision drawing shortly after the payment is received.
