Base Moulding 7" - 37

Base Moulding 7" - 37

This channel baseboard moulding 7" - 29 measures 7.000" wide by .750" thickness, allowing the detail to be machined out of four quarter lumber. The popular profile is comprised of a 5" wide horizontal line in the left center, connected to a 1/2" wide by 1/4" deep dado that joins to a one inch wide raised fillet with a 1/8" radius edge on the top right side of the pattern. We offer two other base moldings in the same width but with different sized dado's as well as a matching casing you may want to review and consider, baseboard 7.000" - 29, baseboard 7.000" - 58 and casing 3.500" - 53.

We're delighted you found a functional profile that interest you, please consider all the other services we offer for your precision woodworking company. Mirror Reflections offers hundreds of tooling supplies for your industrial moulder and knife grinding room. If you're new to the industry read some of our informational articles, they will help you get started with all the basics. One thing we have in common is our passion for excellence and our quest to be paramount craftsman for all our clients.

For knife quoting purposes click to open the calculator below, we have added only the important measurements, just enter the appropriate dimension in the boxes provided. A brief detailed explanation on how to use the calculator is located here. Need some assistance with the dimensions? Print a copy of our fraction - decimal - millimeter chart, place it on the molder to help operators save time and increase accuracy during machine setup.

Width = 7.000" / Depth of Cut = .281" (top knives) & .062" (bottom cutters.)

Molding Knife Calculator

Grade of Steel

Subtotal

$0.00
$0.00
$0.00

Custom Moulding Template

$40.00
$40.00
$40.00

Total
(Template & 2 Knives)

$0.00
$0.00
$0.00

Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%

To purchase this CAD generated, “template ready moulding dxf file”, please send $5.00 via PayPal.Me/MirrorReflections we will email you the precision drawing shortly after the payment is received.
