Bed Mould 4-7/16"

Bed Mould 4-7/16"

Bed Mould 4-7/16"

This elegant bed mould 4-7/16" measures 4.737" wide by .812" thickness, authorizing the pattern to be milled sprung (laying horizontally flat) out of four-quarter lumber. The custom supporting profile is comprised of a 1-5/32" radius convex semicircular arc on the top left, connected to a slightly angled 15/32" tall vertical line segment in the center, joined to a two tangent radius elliptical-shaped cove with a 3/8" wide horizontal line on the bottom right side of the design. The spring angles are fixed at forty-five degrees, these clear back bevels keep the face side of the profile parallel to the wall and ceiling when installed, they also lock in the positioned height at 3-3/16" tall with a projection of 3-5/64" wide.

Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%

Right Cutter Head
Thickness: 1.625
Depth of Cut: 0.480
Left Cutter Head
Thickness: 1.625
Depth of Cut: 0.560
Top Cutter Head
Width: 4.438
Depth of Cut: 0.413
Bottom Cutter Head
Width: 0.000
Depth of Cut: 0.000

Grades of Steel

Price Per Cutter Head - Includes Template & Two Knives

*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$161.75
$118.75
(Template not needed)
$302.40
Not Needed
Total:
$582.90
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$171.25
$128.25
(Template not needed)
$323.15
Not Needed
Total:
$622.65
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$180.75
$137.75
(Template not needed)
$343.90
Not Needed
Total:
$662.40
To purchase this CAD generated, “template ready moulding dxf file” , please send $11.00 to PayPal.Me/MirrorReflections we will email you the precision drawing shortly after the payment is received.
