Door/Window Casing 3" - 65
Door/Window Casing 3" - 65
This creative 3" - 65 door/window casing measures 3.000" width by .750" thickness, necessitating the use of a 3-1/4" wide blank of four-quarter lumber for milling on an industrial moulder. The decorative profile contains a 43/64" wide fillet with a 1/16" eased edge on the top left. The flat section connects to a 13/64" cove with a 5/64" vertical step merged with a 1-31/64" flat line with an additional 1/16" rolled corner in the center. The remaining section contains a 5/32" radius quarter round arc connected to a 7/64" broad fillet, and a 3/16" cove with a 3/64" eased edge on the design's right side. We offer a matching baseboard with similar design characteristics for your review and consideration, baseboard 5.250" - 28.
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
Right Cutter Head
Thickness: 0.000
Depth of Cut: 0.000
Left Cutter Head
Thickness: 0.000
Depth of Cut: 0.000
Top Cutter Head
Width: 3.000
Depth of Cut: 0.733
Bottom Cutter Head
Width: 3.000
Depth of Cut: 0.063
Grades of Steel
Price Per Cutter Head - Includes Template & Two Knives
*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you
currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
Not Needed
Not Needed
$253.00
$238.00
Total:
$491.00
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
Not Needed
Not Needed
$268.00
$253.00
Total:
$521.00
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
Not Needed
Not Needed
$290.50
$275.50
Total:
$566.00
To purchase this CAD generated,
“template ready moulding dxf file”
, please send $11.00 to
PayPal.Me/MirrorReflections
we will email you the precision drawing shortly after the payment is received.
