Crown Moulding 2-3/4" - 18

Crown Moulding 2-3/4" - 18

This fashionable crown moulding 2-3/4" - 18 measures 3.437" wide by .750" thickness, allowing the detail to be milled sprung (horizontally flat) from four quarter lumber. The supporting profile is comprised of a two tangent radius echinus shaped arc flanked by two different sized vertical line segments in the upper level, the lower section consists of a 15/16" cove connected to a 13/64" radius tear drop bead with a 13/64" tall by 7/32" wide squared lines at the bottom of the detail. The spring angles are fixed at thirty-eight and fifty-two degrees, these specific back bevels set the installed height at 2-3/8" tall with a projection of 1-11/16" wide. We also offer a larger version of this profile for your review and consideration, crown molding 3.437" - 13.

Need some supplies for your moulder? Choose any of our quality high speed knife steel or premium carbide, we generally can ship these items the same day. We are also a Weinig authorized agent offering some of the highest quality cutter heads and tooling supplies for your moulder and tool grinding room.

For knife quoting purposes click to open the calculator below, we have added only the important measurements, just enter the appropriate dimension in the boxes provided. A brief detailed explanation on how to use the calculator is located here. Need some assistance with the dimensions? Print a copy of our fraction - decimal - millimeter chart, place it on the molder to help operators save time and increase accuracy during machine setup.

Width = 2.750" / Depth of Cut = .388" (top knives.)

Thickness = .750" / Depth of Cut = .264" (right blades) & .763" (left cutters.)

Molding Knife Calculator

Grade of Steel

Subtotal

$0.00
$0.00
$0.00

Custom Moulding Template

$40.00
$40.00
$40.00

Total
(Template & 2 Knives)

$0.00
$0.00
$0.00

Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%

To purchase this CAD generated, “template ready moulding dxf file”, please send $5.00 via PayPal.Me/MirrorReflections we will email you the precision drawing shortly after the payment is received.
