This professionally drafted cad dxf file contains two high precision template designs to create cutters for this beautiful pattern. From just an idea in one's mind, to reality in their home, our custom profiles reflect the creative style of your imagination, let us help you design a beautiful pattern today.
For knife quoting purposes click to open the calculator below, we have added only the important measurements, just enter the appropriate dimension in the boxes provided. A brief detailed explanation on how to use the calculator is located here. Need some assistance with the dimensions? Print a copy of our fraction - decimal - millimeter chart, place it on the molder to help operators save time and increase accuracy during machine setup.
Width = 3.437" / Depth of Cut = .591" (top knives.)
Thickness = .812" / Depth of Cut = .511" (right blades) & .520" (left cutters.)
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
To purchase a copy of this template ready dxf file for creating acrylic templates to produce knives please send $5.00 via PayPal.Me/MirrorReflections we will email you the dxf file shortly after payment is received.Copyright © Mirror Reflections Inc. All rights reserved.
