Crown 4-13/16" - 1
Crown 4-13/16" - 1
This prestigious 4-13/16" - 1 crown mould measures 4.795" width by .813" thickness, allowing the use of a 5-1/16" blank of four-quarter lumber for milling sprung (laying horizontally flat) on a commercial moulder. The distinguished terminating pattern comprises 13/64" tall by 13/16" broad perpendicular lines on the top left. The segments attach to a 3/16" ovolo merged with a 1-1/2" radius cove and another 3/16" ovolo in the center. The lower portion consists of a 17/32" radius cavetto with a 43/64" broad line segment on the design's bottom right side. The fixed spring angles are set at thirty-eight and fifty-two degrees; these particular back bevels keep the face side of the profile parallel to the wall and ceiling when installed; they also lock in the positioned height at 2-3/4" tall with a 3-15/16" projection across the top.
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
Right Cutter Head
Thickness: 1.625
Depth of Cut: 0.411
Left Cutter Head
Thickness: 1.625
Depth of Cut: 0.667
Top Cutter Head
Width: 4.813
Depth of Cut: 0.495
Bottom Cutter Head
Width: 0.000
Depth of Cut: 0.000
Grades of Steel
Price Per Cutter Head - Includes Template & Two Knives
*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you
currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$166.50
$176.00
$332.28
Not Needed
Total:
$674.78
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$176.00
$185.50
$354.53
Not Needed
Total:
$716.03
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$190.25
$199.75
$387.91
Not Needed
Total:
$777.91
To purchase this CAD generated,
“template ready moulding dxf file”
, please send $11.00 to
PayPal.Me/MirrorReflections
we will email you the precision drawing shortly after the payment is received.
