Baseboard 5-1/4" - 38

Baseboard 5-1/4" - 38
This popular 5-1/4" - 37 base moulding measures 5.250" wide by .718" thickness, permitting the pattern to be milled from four-quarter lumber. The tiered profile comprises a 3-3/16" wide flat line with a 1/8 rounded inside edge on the top left. It's attached to a 1-9/16" flat line segment with another 3/16" drop in elevation with a 1/8" round-over used in transition in the center. It joins to a 1-1/2" wide line with a 1/8" eased edge leaving an 11/32" thickness dimension on the right side of the detail.
We offer many alternative bases & cases with the same style design, here are just a few for your review and consideration, door/window casing 2.250" - 35, casing 3.250" - 71, baseboard 3.250" - 21, baseboard 5.250" - 37 and baseboard 5.750" - 30.
Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%
Right Cutter Head
Thickness: 0.000
Depth of Cut: 0.000
Left Cutter Head
Thickness: 0.000
Depth of Cut: 0.000
Top Cutter Head
Width: 5.250
Depth of Cut: 0.656
Bottom Cutter Head
Width: 5.250
Depth of Cut: 0.063
Grades of Steel
Price Per Cutter Head - Includes Template & Two Knives
*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you
currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
Not Needed
Not Needed
$379.00
$355.00
Total:
$734.00
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
Not Needed
Not Needed
$403.00
$379.00
Total:
$782.00
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
Not Needed
Not Needed
$439.00
$415.00
Total:
$854.00
To purchase this CAD generated,
“template ready moulding dxf file”
, please send $11.00 to
PayPal.Me/MirrorReflections
we will email you the precision drawing shortly after the payment is received.
