Crown Moulding 2-9/32" - 5

Crown Moulding 2-9/32" - 5

This ovolo crown moulding 2-9/32" - 5 measures 2.286" wide by .750" thickness, allowing the pattern to be milled from four quarter lumber. The elegantly stylish profile is composed of a 2-23/64" radius semicircular arc in the center, flanked by a 7/16" tall by 3/8" wide squared lines on top and 7/16" tall by 13/32" wide squared lines at the bottom of the pattern. The spring angles are fixed at thirty-eight and fifty-two degrees, these specific back bevels set the installed height at 2-9/16" tall with a projection of 2-1/16" wide.

Utilize some of our user-friendly moulding profiles, all professionally designed by an accomplished draftsman/toolmaker with over thirty-five years of experience in woodworking and former Weinig moulder/grinder field service technician. From just an idea in one's mind, to reality in their home, our custom profiles reflect the creative style of your imagination, let us assist you in complementing the architectural decor of any room with one of our attractive molding patterns.

For knife quoting purposes click to open the calculator below, we have added only the important measurements, just enter the appropriate dimension in the boxes provided. A brief detailed explanation on how to use the calculator is located here. Need some assistance with the dimensions? Print a copy of our fraction - decimal - millimeter chart, place it on the molder to help operators save time and increase accuracy during machine setup.

Width = 3.281" / Depth of Cut = .429" (top knives.)

Thickness = .750" / Depth of Cut = .388" (right blades) & .571" (left cutters.)

Molding Knife Calculator

Grade of Steel

Subtotal

$0.00
$0.00
$0.00

Custom Moulding Template

$35.00
$35.00
$35.00

Total
(Template & 2 Knives)

$0.00
$0.00
$0.00

Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%

To purchase a copy of this template ready dxf file for creating acrylic templates to produce knives please send $5.00 via PayPal.Me/MirrorReflections we will email you the dxf file shortly after payment is received.
