Crown Moulding 5-15/16" - 10

This decorative crown molding 5-31/32" - 3 measures 5.968" wide by .687" thickness. The beautiful profile contains a 41/64" quarter circle on the top left. The semicircular arc connects to a three tangent radius cyma recta flanked by a 7/32" vertical line above, and a 5/8" tall vertical line underneath, attached to a small cyma reversa flanked by a short vertical and horizontal line at the bottom of the design. The spring angles are cutting at thirty-eight and fifty-two degrees, these specific back bevels set the installed height at 3-11/16" tall with a projection of 4-11/16" wide. Three high points in the detail are deliberately positioned on the same plane; this specialized design feature will assure excellent hold down conditions while milling, providing the machines pressure shoe is parallel to the bed plates.

Custom-made elegance is a phrase used to define the beauty, style and artisanship of thousands of our moulding designs. Whether you own a recently built house or older style residence, we have the ability knowledge and experience to create profiles that will complement the architectural decor of your elegant home or office.

For knife quoting purposes use the calculator below, we have added only the important measurements, just determine the cutters you need. A brief detailed explanation on how to use the calculator is located here. Need some assistance with the dimensions? Print a copy of our fraction - decimal - millimeter chart, place it on the moulder to help operators save time and increase accuracy during machine setup.

Width = 5.968" / Depth of Cut = .358" (top knives).

Thickness = .687" / Depth of Cut = .387" (right blades) & .608" (left cutters).
