Crown 4-1/4" - 51

Crown 4-1/4" - 51

Crown 4-1/4" - 51

This 4-1/4" - 51 ovolo crown mould measures 4-1/4" wide by .750" thickness. The symmetrical profile is comprised of a 4-17/32" radius arc in the center, attached to a 7/16" horizontal and vertical fillet that transitions into a 1/2" wide & tall straight line positioned at the top and bottom of the pattern. The spring angles are fixed at forty-five degrees, setting the installed height and projection at an identical dimension of 3-3/16" tall and wide. We have a large group of similar style profiles with different widths, heights, and projections; here are just a few you may want to review & consider for your current woodworking job, crown 2.000" - 14, crown 2.500" - 13, crown 3.000" - 3, crown 3.250" - 23, crown 5.250" - 11, crown 6.375" - 13, and crown 8.500" - 11.

Note: If you’re experiencing trouble printing to Full Scale, Go to File, Print Preview. Change the “Shrink to Fit” option to 100%

Right Cutter Head
Thickness: 1.625
Depth of Cut: 0.413
Left Cutter Head
Thickness: 1.625
Depth of Cut: 0.413
Top Cutter Head
Width: 4.250
Depth of Cut: 0.430
Bottom Cutter Head
Width: 0.000
Depth of Cut: 0.000

Grades of Steel

Price Per Cutter Head - Includes Template & Two Knives

*If you want only to purchase the profile templates, review our price list
*All listed cutter head prices may not be necessary based on what you currently own
V2+RW
chrome coated 72rc face, best seller
great tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$161.75
$118.75
(Template not needed)
$293.00
Not Needed
Total:
$573.50
Black Nitride
black nitride case hardened 72rc
medium size runs
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$171.25
$128.25
(Template not needed)
$313.00
Not Needed
Total:
$612.50
Endurance
chrome and diamond coated
longest tool life
Right Cutter Head:
Left Cutter Head:
Top Cutter Head:
Bottom Cutter Head:
$180.75
$137.75
(Template not needed)
$333.00
Not Needed
Total:
$651.50
To purchase this CAD generated, “template ready moulding dxf file” , please send $11.00 to PayPal.Me/MirrorReflections we will email you the precision drawing shortly after the payment is received.
